Microbit Voting System

In this step-by-step lesson, you'll create a secure voting system using microbits. You'll program voting and central microbits, set up voting buttons, receive and reset votes, display results, and test your system. Finally, you'll enhance your project by adding a security feature to ensure the integrity of the votes.
Learning Goals Learning Outcomes Teacher Notes Lesson Files

Live Class Feed

This is a live feed of the latest activity by your students on this lesson. It will update in real-time as they work on the lesson.
Load previous activity

    1 - Create a Project

    In this lesson, you will create a voting system using microbits. This system will consist of multiple 'voting' microbits and one 'central' microbit. Each voting microbit will be able to cast a single vote, which will be sent to the central microbit. The central microbit will tally the votes and display the results. Additionally, the central microbit will have the ability to reset the voting state of all the voting microbits, allowing for a new round of voting to take place.

    To start, you will need to create two separate projects on the MakeCode Microbit website. One project will be for the voting microbits, and the other will be for the central microbit. Let's begin with the voting microbits project.

    Go to the MakeCode Microbit website (https://makecode.microbit.org/) and click on 'New Project'. Name this project 'Voting Microbit'. Once you have created this project, repeat the process to create a second project and name it 'Central Microbit'. These two projects will allow you to code the different functionalities required for the voting and central microbits.


    2 - Set up the Voting Buttons

    In this step, we will program the A and B buttons on your microbit to allow only a single 'Yes' or 'No' vote. Once a vote has been cast, the microbit will not accept any more votes. This is achieved by creating a variable 'voted' that tracks whether a vote has been cast or not.

    First, let's create the 'voted' variable and set it to false. This means that at the start, no vote has been cast yet. Add the following code to the 'Voting Microbit' project:

    let voted = false
    voted = false
    radio.setGroup(1)
    basic.showString("?")


    Now, let's program the A and B buttons. We want them to send a 'Yes' or 'No' vote only if 'voted' is false, i.e., no vote has been cast yet. Once a vote is cast, we set 'voted' to true to prevent further voting.

    Add the following code:

    input.onButtonPressed(Button.A, function () {
        if (!(voted)) {
            radio.sendString("yes")
            voted = true
            basic.showIcon(IconNames.Yes)
        }
    })

    input.onButtonPressed(Button.B, function () {
        if (!(voted)) {
            radio.sendString("no")
            voted = true
            basic.showIcon(IconNames.No)
        }
    })


    This code checks if 'voted' is false before sending a 'Yes' or 'No' vote. If 'voted' is true, it means a vote has already been cast and it will not send another vote. Once a vote is sent, it sets 'voted' to true, preventing further votes from being cast.

    3 - Set up the Vote Receiver and Reset

    In this step, we will set up the central microbit to receive votes and to send a reset signal. This will allow us to count the votes and reset the voting system when needed.

    First, we need to create two variables 'yesCount' and 'noCount' to keep track of the number of 'Yes' and 'No' votes. We also need to connect our microbit to a radio group. This allows our microbits to communicate with each other. You can do this by adding the following code:

    let yesCount = 0
    let noCount = 0
    radio.setGroup(1)

    Next, we will write a function to handle the received votes. If the received string is 'Yes', we will increase the 'yesCount' by 1. If the received string is 'No', we will increase the 'noCount' by 1. Add the following code:

    radio.onReceivedString(function (receivedString) {
    	if (receivedString == 'Yes') {
        	yesCount += 1
        } else if (receivedString == 'No') {
        	noCount += 1
        }
     })

    Finally, we will set up a function to reset the counts of 'Yes' and 'No' votes and send a 'Reset' radio message to all microbits when both buttons A and B are pressed at the same time. Add the following code:

    input.onButtonPressed(Button.AB, function () {
    yesCount = 0
    noCount = 0
    radio.sendString('reset')
    })

    Now, your central microbit is set up to receive votes, count them, and reset the voting system when needed.

    4 - Receive the Reset Signal

    Next, let's set up the individual voting microbits to receive the 'Reset' signal from the central microbit. Add the following code to the 'Voting Microbit' project:

    radio.onReceivedString(function (receivedString) {
        if (receivedString == "reset") {
            voted = false
            basic.showString("?")
        }
    })


    This code will reset the voted state to false when the 'Reset' signal is received, allowing the microbit to vote again.

    Download the code onto all the 'Voting Microbit' microbits.

    5 - Display the Vote Results

    Let's continue to display the vote results on the central microbit as before. The existing code from the previous lesson can be reused:

    basic.forever(function () {basic.showString('Yes:' + yesCount + ' No:' + noCount)})

    Download this code onto the 'Central Microbit'.
